PuttyMaster PM-5000 SeriesIndustrial Putty & Sealant Filling SystemHigh-Viscosity Precision • 45 Tubes/Min • ±0.5% Accuracy • Zero-Clog • CE/ISO CertifiedCore Technical SpecificationsParameterPM-5
Industrial Putty & Sealant Filling System
High-Viscosity Precision ? 45 Tubes/Min ? ±0.5% Accuracy ? Zero-Clog ? CE/ISO Certified
| Parameter | PM-5100 (Standard) | PM-5200H (High-Viscosity) | PM-5300F (Food-Grade) |
|---|---|---|---|
| Capacity | 50ml-1kg (±0.5%) | 100ml-5kg (±0.8%) | 50ml-1kg (±0.3%) |
| Throughput | 45 Tubes/Min | 35 Tubes/Min | 40 Tubes/Min |
| Viscosity Range | 50,000-2,000,000 cP | 100,000-5,000,000 cP | 10,000-1,000,000 cP |
| Accuracy | ±0.5% Gravimetric | ±0.8% | ±0.3% |
| Filling Technology | Twin-Screw Auger<br>? Tungsten Carbide Screw (2,200 Hv)<br>? Shear-Thinning Design<br>? 200g/sec Flow Rate | Hydraulic Piston + Pre-Heating | Peristaltic Pump (FDA) |
| Material Compatibility | Putty ? Caulk ? Sealant ? Epoxy ? Adhesive ? Silicone | Thixotropic Materials | NSF-Certified Compounds |
| Clog Prevention | Anti-Bridging System:<br>1. Pulsed Vibration Agitator<br>2. Rotating Scraper Blades<br>3. PTFE-Lined Hopper | Heated Path (40-80°C) | Ultrasonic Flow Aid |
| Tube Handling | Automatic Tube Feeder<br>Size: ?20-75mm<br>Length: 100-300mm<br>Materials: PE/PP/Aluminum | Same + Cartridges | Collapsible Laminates |
| Nozzle Options | Tapered ? Flat ? Recessed<br>Materials: Tungsten Carbide ? PTFE ? Ceramic | Custom Profiles | Sanitary Tri-Clamp |
| Changeover Time | <5min (Tool-Free) | <8min | <4min |
| Power | 380V/50Hz, 5.5kW | 380V/50Hz, 7.2kW | 380V/50Hz, 4.8kW |
| Certifications | CE ? ISO 9001 | ATEX Zone 22 | FDA 21 CFR 177.2600 |
Performance Validation:
| Material | Viscosity | Clog Incidents | Industry Standard |
|---|---|---|---|
| Acrylic Putty | 800,000 cP | 0/8hr Shift | 3-5/Shift |
| Silicone Sealant | 1,200,000 cP | 0/8hr Shift | 4-7/Shift |
| Epoxy Filler | 1,500,000 cP | 0/8hr Shift | 5-8/Shift |
| Component | Technology | Performance |
|---|---|---|
| Load Cells | Temperature-Compensated (ASTM E74) | ±0.1% FS Accuracy |
| Auger Drive | Servo Motor + Planetary Gearbox | 0.1 RPM Resolution |
| PID Control | Adaptive Algorithm | ±0.5% Fill Consistency |
Construction & DIY
| Material | Packaging Format | Specialized Features |
|---|---|---|
| Wall Putty | 300ml-1kg Tubes | Anti-Settling Pulsed Agitation |
| Wood Filler | 50-250ml Cartridges | Low-Shear Mixing (0% Fiber Damage) |
| Concrete Repair | 500g-3kg Pails | Abrasion-Resistant Tungsten Carbide |
Automotive & Industrial
High-Performance Sealants:
Static Control:
| Feature | Specification |
|---|---|
| Ionized Air Curtain | 10? ions/cm3 Output |
| Conductive Path | Surface Resistivity <10? Ω |
Food & Pharma
| Requirement | Technical Solution | Certification |
|---|---|---|
| Hygienic Design | EHEDG EL Class I Surfaces | 3-A Sanitary Standard |
| Material Safety | USP Class VI Certification | FDA 21 CFR 175.300 |
| Cleanability | CIP/SIP Validation | ISO 22000 |
1. Tube Auto-Loading → 2. Nozzle Alignment (±0.3mm) → 3. Precision Filling (±0.5%) → 4. Vacuum Degassing → 5. Heat Sealing/Capping → 6. Weight Verification → 7. Carton Packing
Cycle Time: 1.3 seconds/tube
Heavy-Duty Performance
? Clog-Free Guarantee: | **Technology**| **Performance**| |-------------------------|------------------------| | Helical Agitator | 15 RPM ±0.1 RPM| | Ultrasonic Vibrator| 40kHz ±1kHz| | Self-Cleaning Auger| Hardox 500 Scraper Blades | ? Extreme Viscosity Handling: 1. 5,000,000 cP Capability 2. Shear-Thinning Screw Design 3. 60°C Pre-Heating System ? Industrial Durability: - Tungsten Carbide Screw (50,000-Hour Lifespan) - IP65 Washdown Protection - 100,000-Hour MTBF
? CE Machinery Directive 2006/42/EC ? ISO 9001:2015 Quality Management ? ATEX 2014/34/EU Zone 22 (Optional) ? FDA 21 CFR 175.300 (Food-Grade Model)
Henkel Construction Products:
"After implementing PM-5200H for silicone sealant:
Output: 22 → 45 Tubes/Min (+105%)
Material Waste: 4.2% → 0.18%
Downtime: 8hrs/week → 0.5hrs/week
ROI Period: 5 months"
APPLICABLE BARREL TYPE
