Unipulse F701-C weighing controller with accumulation function
F701-C is a general-purpose weighing controller that is compatible with all weighing systems. This is a practical device excellent in cost effectiveness, which is equipped with the final discharge function allowing high-accuracy feeding and discharging weighing control and the weighing sequence function essential to hopper and packing scales.
Installable is the interface that can be connected to PLCs or various peripherals such as BCD output, RS-232C and CC-Link.
| ANALOG SECTION | |
| Excitation voltage | 10V DC ±5%, Output current; within 120mA (Up to 4 loadcells at 350Ω are parallel-connectable) |
|---|---|
| Zero adjustment range | 0 - 2mV/V Rough adjustment: Digitally controlled via rough adjustment circuit Fine adjustment: Auto adjusting method via digital processing |
| Gain adjustment range | 0.3 - 3.2mV/V Rough adjustment: Digitally controlled via rough adjustment circuit Fine adjustment: Auto adjusting method via digital processing |
| Min. input sensitivity | 0.3μV / count |
| Accuracy | Non-linearity: within 0.01% FS Zero drift: within 0.2μV/°C RTI Gain drift: within 15 ppm/°C |
| Analog filter | Bessel low-pass filter (-12dB/oct.), Selectable from 2, 4, 6, 8 Hz |
| A/D converter | Speed: 200 times/sec Resolution: 24 bit (binary) |
| SETTING SECTION | |
| Setting items | - High limit, Low limit, near zero, SP1, SP2, Compensation, over, under, final - Comparison inhibit time, judging time, complete output time, adjust feeding time, auto zero times, judging times. Auto free fall compensation regulation, analog filter, tare weight - Weighing function 1, weighing function 2, weighing function 3, sequence mode, function key inhibit, digital filter, motion detect, zero tracking period, zero tracking range - Balance weight value, capacity, min. scale division, net over, gross over, DZ regulation value, function selection, gravitation acceleration (area number input), gravitation acceleration (acceleration input) - D/A output mode, D/A zero output weight, D/A full scale, RS-485 I/F, ID number, RS-232C I/F, external function selection, setting value LOCK, restriction on the tare subtraction function - Input selection, output selection, CC-Link I/F Occupied station & Transmission speed, CC-Link I/F Station No. - Average weight, maximum weight, minimum weight, population standard deviation, sample standard deviation, number of data (n), latest accumulation date, Maximum-minimum (R), option substrate - Span calibration, equivalent input calibration, password input, zero calibration |
|---|---|
| INPUT/OUTPUT SECTION | |
| External output signal | Transistor’s open collector output (Emitter = COM terminal); Output is LO when transistor is ON. Near zero, SP1, SP2, SP3, under, over, Low limit, high limit, stable, weight alarm or error, go or complete, run or accumulation error |
|---|---|
| External input signal | ON when shorted to COM terminal by contact (relay, switch) or non contact (TTL-level transistor or open collector output) G/N, digital zero, tare subtraction ON, tare subtraction OFF, hold*, judge*, feed / discharge, start*, stop*, accumulation command*, accumulation clear* *Signals for selection. Up to 4 can be selected. |
| Interface |
|
| DISPLAY SECTION | |
| Display unit | Numerical display (7 digits) with a character height of 10.4 mm by fluorescent display tube, Sub-display; character height 4.0 mm |
|---|---|
| Display value | 5 digits, Sign; Minus sign displayed on most significant digit |
| Unit | Selectable from t, kg, g, N, lb, none |
| Status display | SP1, SP2, SP3, NEAR ZERO, HOLD, ZERO ALARM, STAB, TARE, NET, ZERO, BATTERY CONDITIONS |
| GENERAL SPECIFICATIONS | |
| Power supply voltage | 100 - 240V AC (+10% - 15%) (Free power supply 50/60 Hz) |
|---|---|
| Power consumption | Approx. 15VA |
| Operating conditions | Temperature: Working temperature range -10 - +40°C; Storage temperature range -20 - +85°C Humidity: 85% RH or less (non-condensing) |
| External dimensions | 144 (W) x 72 (H) x 160 (D) [mm] (protruding parts not included) |
| Weight | Approx. 1.0 g |
| OPTION | |
| BCO | BCD parallel data output interface |
|---|---|
| 485 | RS-485 communication interface |
| DAC | D/A converter interface |
| CCL | CC-Link interface |
| Number of mountable options | 1 |
| ACCESSORIES | |
| AC input cord (nominal rating: 125V) 3m | 1 |
|---|---|
| Mini-driver | 1 |
| FCN series I/O connector (with cover) | 1 |
| Jumper cable | 2 |
| Operation Manual | 1 |
| BCD output connector (when BCD output option is installed) | 1 |
| RS-485 connector (when RS-485 option is installed) | 1 |
| D/A converter connector (when D/A converter option is installed) | 1 |
| CC-Link connector (when CC-Link option is installed) | 1 |
| Model | Description |
| BCO | BCD parallel data output interface |
|---|---|
| 485 | RS-485 communication interface |
| DAC | D/A converter interface |
| CCL | CC-Link interface |
| Model | Description |
| CAAC2P-B3 | AC Supply cord 3m |
|---|---|
| CAAC3P-CEE7/7-B2 | AC Supply cord (Voltage resistance:250V)2m |
| CN34 | D-Sub 9p connector for RS-232 |
| CN50 | FCN series I/O connector (with cover) |
| CN55 | FCN series I/O connector (with diagonal cover) |
| CN70 | D/A converter connector |
| CN71 | RS-485?CC-Link connector |
| CN80 | Analog I/O connector terminal |
| F720 mounting panel | Mounting panel for F252 / F280 to F701-C conversion |
| LB01-XH | Lithium battery (with XH connector) |
