It is an economical filling robot product developed for customers with high production capacity, high degree of automation, and the characteristics of new 200L filling containers. It is suitable for l
Economical Liquid Inks Filling Machine
Smart Value. Essential Performance.
IE-3000 redefines cost-efficient ink packaging with ±0.5% accuracy at 150 bottles/hour, delivering 80% cost savings vs premium systems while maintaining critical functionalities:
Anti-settling paddle agitator (50-30,000 cP)
Solvent vapor capture (>95% efficiency)
Pantone? color validation (ΔE<0.8)
Tool-free quick changeover (<3 min)
Parameter | Specification |
|---|---|
Capacity Range | 100ml-5L (±0.5%) |
Throughput | 150 bottles/hour |
Accuracy | ±0.5% volumetric |
Viscosity Range | 50-30,000 cP |
Material Contact | 304 SS + PTFE seals |
Agitation System | Variable-speed paddle (10-60 RPM) |
Power | 220V/50Hz, 1.8kW |
VOC Control | Activated carbon adsorption (95%) |
Footprint | 1200×800×1600mm |
Changeover Time | <3 min (no tools) |
Operational Economics:
Upfront Cost: **75,000+ for full-auto)
Energy Use: 0.12 kWh/batch (60% less than auto lines)
Maintenance: <$500/year (seals/paddle only)
Feature | Economy Solution | Performance |
|---|---|---|
Pigment Settling | Paddle agitation (30 RPM) | >90% uniformity |
Solvent Exposure | Fume extraction hood | TWA <5ppm (OSHA) |
Static Control | Grounded stainless steel | <10? Ω (NFPA 77) |
Metric | Premium Filler | IE-3000 | Savings |
|---|---|---|---|
Unit Cost | $82,000 | $18,500 | ↓77% |
Accuracy | ±0.1% | ±0.5% | Adequate for 90% applications |
Operator Labor | 0.5 FTE | 1 FTE | +0.5 FTE but ↓$64k CAPEX |
Power Consumption | 0.35 kWh/batch | 0.12 kWh/batch | ↓66% |
? Small print shops (10-50L/day) ? Ink R&D laboratories ? Educational institutions ? Regional distributors (private labeling)
Real-World Case:
Vietnam’s Minh Long Printing
Challenge: $65k budget for 100 bottles/hour
Solution: 2× IE-3000 units @ $37k total
Result:
? 150 bottles/hour actual output
? ROI: 4 months
? Color consistency ΔE<0.9
? CE EN 60204-1 (Safety) ? OSHA 1910.106 (Flammable Liquids) ? Pantone? Basic Validation ? RoHS/REACH Material Compliance
Module | Function | Price |
|---|---|---|
Digital Scale | Gravimetric verification (±1%) | $950 |
Enhanced Agitation | Helical stirrer (100,000 cP) | $1,850 |
VOC Scrubber | >99% solvent capture | $3,200 |
Recipe Memory | 50-program storage | $650 |
Key Advantage: 60% lower TCO vs automated systems
Package | Delivery | Pricing |
|---|---|---|
Base Unit | EXW Shanghai | $18,500 |
Starter Kit | Includes: | $21,000 |
- VOC hood | ||
- 3 nozzle sizes | ||
- Tool kit | ||
Global Shipping | CIF major ports | +$1,800 |
Precision Within Reach
Shanghai Guangzhi IE-3000: Democratizing professional ink filling – delivering essential Pantone? consistency for small batch producers at 1/4 the cost.
Value-Driven Advantages
? 77% Cost Savings: vs automated systems
? Pantone? Compatible: ΔE<0.8 with manual verification
? Zero Settling: Adjustable paddle agitation
? Easy Maintenance: Tool-free component access
