ChemiFill Pro CP-3000 SeriesIntegrated 30L Chemical Bottle & Pail Filling-Capping SystemPrecision Liquid Handling • 120 Units/Hr • ±0.15% Accuracy • ATEX/FDA Dual Compliance • Zero-Spill Technolog
Integrated 30L Chemical Bottle & Pail Filling-Capping System
Precision Liquid Handling ? 120 Units/Hr ? ±0.15% Accuracy ? ATEX/FDA Dual Compliance ? Zero-Spill Technology
| Parameter | CP-3100 (Standard) | CP-3200X (ATEX) | CP-3300P (Pharma-Grade) |
|---|---|---|---|
| Capacity | 30L (±0.15%) | 30L (±0.2%) | 30L (±0.1%) |
| Throughput | 120 Units/Hr | 110 Units/Hr | 100 Units/Hr |
| Accuracy | ±0.15% Gravimetric | ±0.2% | ±0.1% |
| Viscosity Range | 5-500,000 cP | 10-300,000 cP | 50-1,000,000 cP |
| Container Compatibility | Bottles (5-30L) ? Pails ? Jerrycans<br>Materials: HDPE ? PP ? Stainless Steel | Same + Safety Cans | USP Containers |
| Filling Technology | Servo Piston + Coriolis Meter | ATEX Gear Pump | Peristaltic Pump (FDA) |
| Capping Technology | Robotic Torque Control<br>? 5-100 N·m Range<br>? ±0.5% Accuracy<br>? Auto Thread Detection | Magnetic Clutch System | Servo Stepper Motor |
| Material Contact | 316L SS (Ra<0.8μm) | Hastelloy C276 | 316L EP (Ra<0.4μm) |
| Spill Control | TripleSeal? System:<br>1. Vacuum Hood (-35Pa)<br>2. Coanda Adhesion Nozzle<br>3. Ionized Air Curtain | + Nitrogen Blanketing | VHP Sterilization |
| Cap Types | Screw ? Press ? Lug ? Child-Resistant | Same + Vapor-Lock Caps | Tamper-Evident Seals |
| Changeover Time | <60s (Tool-Free) | <75s | <50s |
| Power | 380V/50Hz, 5.5kW | 24VDC Ex ia | 380V/50Hz, 4.8kW |
| Certifications | CE, ISO 9001 | ATEX Zone 2 | FDA 21 CFR 210/211 |
Performance Validation:
| Chemical | Viscosity | Spill Volume | Industry Standard |
|---|---|---|---|
| Sulfuric Acid | 25 cP | 0.2ml | 8-15ml |
| Silicone Oil | 50,000 cP | 0.3ml | 10-20ml |
| Solvent Blend | 300 cP | 0.1ml | 5-12ml |
| Technology | Function | Efficiency |
|---|---|---|
| Activated Carbon Adsorption | VOC Capture | 99.95% @ 20°C |
| Condensation Recovery | -40°C Cryogenic Cooling | 98% Solvent Recovery |
| O? Monitoring | Zirconia Sensor (0-25%) | ±0.1% Accuracy |
Chemical Processing
| Feature | ATEX Solution | Certification |
|---|---|---|
| Static Control | Ionized Air Curtain (10? ions/cm3) | NFPA 77 |
| Corrosion Resistance | Zirconium Alloy Flow Path | NACE MR0175 |
| Explosion Safety | Nitrogen Inerting (O?<8%) | ATEX Category 2G |
Pharmaceuticals
cGMP Compliance:
Data Integrity:
| System | 21 CFR Part 11 Feature |
|---|---|
| Audit Trail | Blockchain Timestamping |
| Electronic Signatures | RSA-2048 Encryption |
Food & Cosmetics
| Requirement | Technical Solution |
|---|---|
| Allergen Control | Dedicated Change Parts |
| Oxygen Barrier | Nitrogen Flushing (O?<0.1%) |
| Cleanability | CIP 15-min Cycle (ATP<5 RLU) |
**10" HMI with ChemiOS?**
AI-Driven Features:
Quality Sentinel:
| Parameter | Action |
|---|---|
| pH Shift >0.3 | Flow Pause + Alert |
| Density Variance >1% | Formula Recalibration |
Zero-Downtime:
| Component | Alert Threshold |
|---|---|
| Seal Wear | Friction >8N |
| Pump Cavitation | Vibration >4.5mm/s |
Precision Engineering
? Spill-Free Architecture: | **Technology**| **Performance**| |-------------------------|------------------------| | Vacuum Hood| -35Pa ±2Pa| | Coanda Nozzle| 0 Droplet Formation| | Ionized Air Curtain| Static <0.5kV| ? Capping Perfection: 1. ±0.5% Torque Accuracy (5-100 N·m) 2. 0.2mm Thread Defect Detection 3. <3s Cap-Type Changeover ? Industrial Durability: - Tungsten Carbide Contact Points - IP69K Washdown Protection - 100,000-Hour MTBF
? ATEX 2014/34/EU Zone 2 ? FDA 21 CFR 210/211 ? EHEDG EL Class I ? ISO 9001:2015
BASF Chemical Packaging Line:
"After 6 months using CP-3200X:
Output: 85 → 120 Units/Hour (+41%)
Spill Reduction: 98% (1.5L/shift → 0.03L/shift)
Cap Defect Rate: 2.1% → 0.04%
VOC Emissions: ↓96% (Carbon Adsorption)"
APPLICABLE BARREL TYPE
